Cisco SFP-10G-LR Compatible 10GBASE-LR SFP+ Transceiver Module (SMF, 1310nm, 10km, LC, DOM)
Cisco SFP-10G-LR Compatible SFP+ transceiver supports up to 10km link lengths over LC duplex SMF fiber. This transceiver is compliant with SFF-8431, SFF-8432 and IEEE 802.3ae standards. Digital diagnostics monitoring is available via a 2-wire serial interface, as specified in SFF-8472. Featuring low power consumption, high speed, this 10G SFP+ transceiver is ideal for data center, enterprise wiring closet, service provider transport application, Radio & Baseband Unit, etc.
Specifications
|
Compatible |
SFP-10G-LR |
Vendor Name |
Longline |
|
Form Factor |
SFP+ |
Max. Data Rat5 |
10.3125Gbps |
|
Wavelength |
1310nm |
Max. Cable Distance |
10km |
|
Connector |
Duplex LC |
Media |
SMF |
|
Transmitter Type |
DFB |
Receiver Type |
PIN |
|
TX Power |
-8.2~-0.5dBm |
Receiver Sensitivity |
< -14.4dBm |
|
Powerbudget |
3.8dB |
Receiver Overload |
0.5dBm |
|
Typical Power Consumption |
<1W |
Extinction Ratio |
>3.4dB |
|
Commercial Temperature Range |
0 to 70°C (32 to 158°F) |
Protocols |
IEEE 802.3ae, SFF-8472, SFF-8431, SFF-8432, SFP+ MSA Compliant, CPRI, eCPRI |
